Specifications:
☉Standard: ASTM B111 (GB/T-1527 )
☉Materials: C44300(HSn70-1), C68700Hal77-2), C70600(BFe10-1-1) , C26000(H70), C33000(HPb66-0.5) etc.
☉ Outside diameter: 6.35 to 133mm
☉ Thickness: 0.4 to 12mm
☉ Length: 6000 to 25000mm
☉ Process methods: cold drawn and cold rolled
☉ Surface: pickled or sand blasting
Features:
☉ Small external diameter
☉ High precision
☉ Smooth internal and external surface
Applications:
☉ Air conditioner and refrigerator
☉ Water tube service and distribution
☉ Fire protection, solar and fuel/fuel oil
☉ Natural gas and liquefied petroleum gas (LPG)
☉HVAC, snow melting, drain, waste and vent piping
☉ Heat exchange
☉ Widely used in boiler, heat exchange, oil and chemical industry
Packing:
☉ Seaworthy packing
☉ With plastic cap to protect both ends
☉ Plastic bag wrapped outside pipe
☉ Bundles to be covered by polythene and strapped securely
☉Pack with wooden box
Specification as below:
Quantity: | |
---|---|
Specification | Thickness (mm) | Length (mm) | |||||||||||
0.4 | 0.4-1 | 1-2 | 2-3 | 3-4 | 4-5 | 5-6 | 6-7 | 7-8 | 8-10 | 10-12 | ≤25000 | ||
O.D. (mm) | 6.35-10 | √ | √ | ≤25000 | |||||||||
>10-20 | √ | √ | √ | √ | √ | ≤25000 | |||||||
>20-50 | √ | √ | √ | √ | √ | √ | √ | ≤25000 | |||||
>50-100 | √ | √ | √ | √ | √ | √ | √ | √ | √ | ≤15000 | |||
>100-133 | √ | √ | √ | √ | √ | √ | √ | √ | ≤6000 | ||||
Remarks | ☉ Mraks with √ are supplied ☉ Standard: ASTM B111 (GB/T-1527 ) ☉ Materials: C44300(HSn70-1). C68700Hal77-2). C70600(BFe10-1-1) .C26000(H70). C33000(HPb66-0.5) etc. ☉ Outside diameter: 6.35 to 133mm ☉ Thickness: 0.4 to 12mm ☉ Length: 6000 to 25000mm | ||||||||||||
Packing | ☉ With plastic cap to protect both ends ☉ Plastic bag wrapped outside pipe ☉Pack with wooden box ☉As requirements |
