Specifications:
☉Standard: ASTM B111 (GB/T-1527 )
☉Materials: C10200(TU2) , C12200(TP2) , C2680(H68) , C27200(H63), C27000(H65)
☉ Outside diameter:6.35 to 69.85mm
☉Thickness: 0.4 to 3.05mm
☉Process methods: cold drawn and cold rolled
Features:
☉ Small external diameter
☉ High precision
☉ Smooth internal and external surface
Applications:
☉ Air conditioner and refrigerator
☉ Water tube service and distribution
☉ Fire protection, solar and fuel/fuel oil
☉ Natural gas and liquefied petroleum gas (LPG)
☉ Heat exchange
Packing:
☉ With plastic cap to protect both ends
☉ Plastic bag wrapped outside pipe
☉ Pack with wooden box
☉ As requirements
Specification as below:
| Quantity: | |
|---|---|
| Specifications | Thickness (mm) | ||||||||
| 0.4-0.58 | 0.58-0.79 | 0.79-0.99 | 0.99-1.19 | 1.19-1.50 | 1.50-1.98 | 1.98-3.05 | 3.05 | ||
| O.D. (mm) | 6.35-12.70 | √ | √ | √ | √ | √ | |||
| 12.70-19.05 | √ | √ | √ | √ | √ | √ | √ | √ | |
| 19.05-25.40 | √ | √ | √ | √ | √ | √ | √ | √ | |
| 25.40-34.93 | √ | √ | √ | √ | √ | √ | √ | √ | |
| 34.93-50.80 | √ | √ | √ | √ | √ | √ | √ | ||
| 50.80-69.85 | √ | √ | √ | ||||||
| Remarks | ☉Tubes with marks √are supplied ☉Standard: ASTM B111 (GB/T-1527 ) ☉Materials: C10200(TU2) . C12200(TP2) . C2680(H68) . C27200(H63). C27000(H65) ☉Outside diameter:6.35 to 69.85mm ☉Thickness: 0.4 to 3.05mm ☉Any requirement about the specification,please contact us. | ||||||||
| Packing | ☉ With plastic cap to protect both ends ☉ Pack with wooden box ☉ As requirements | ||||||||
