HMFH022013
Straight Micro Steel Fibers | ||||||
Type | Diameter (mm) | Length (mm) | Cross Section | Shape | Material | Tensile Strength (MPa or N/mm²) |
MFH016006 | 0.16 ± 10% | 6 ± 1.5 | round | Straight | carbon steel 1.4301 / AISI 304 1.4401 / AISI 316 to be negotiated | min. 1400 |
MFH016010 | 0.16 ± 10% | 10 ± 1.5 | ||||
MFH016013 | 0.16 ± 10% | 13 ± 1.5 | ||||
MFH016014 | 0.16 ± 10% | 14 ± 1.5 | ||||
MFH175006 | 0.175 ± 10% | 6 ± 1.5 | ||||
MFH175010* | 0.175 ± 10% | 10 ± 1.5 | ||||
MFH175125* | 0.175 ± 10% | 12.5 ± 1.5 | ||||
MFH175014* | 0.175 ± 10% | 14 ± 1.5 | ||||
MFH020006* | 0.20 ± 10% | 6 ± 1.5 | ||||
MFH020010* | 0.20 ± 10% | 10 ± 1.5 | ||||
MFH020013* | 0.20 ± 10% | 13 ± 1.5 | ||||
MFH020014* | 0.20 ± 10% | 14 ± 1.5 | ||||
MFH030125 | 0.30 ± 10% | 12.5 ± 1.5 | ||||
MFH030020 | 0.30 ± 10% | 20 ± 1.5 | ||||
MFH033125 | 0.33 ± 10% | 12.5 ± 1.5 | ||||
MFH033020 | 0.33 ± 10% | 20 ± 2 | ||||
MFH040125* | 0.40 ± 10% | 12.5 ± 1.5 | ||||
MFH040020 | 0.40 ± 10% | 20 ± 2 | ||||
MFH040025 | 0.40 ± 10% | 25 ± 2.5 | ||||
Packing | in bags of 20 / 25/ 500 / 1000 Kgs net each, 500/1000/1200Kg on pallets, as the request | |||||
Remarks | 1. Micro steel fibers comply with ASTM A820 TYPE I standard. Brass Coated Steel Fibers with Marks* comply with CE Certificate EN 14889-1: 2006. 2. If you would have any special requirements of the specifications, I.E. diameter, length, tensile strength, materials etc., please don't hesitate contact us. | |||||
Straight Micro Steel Fibers | ||||||
Type | Diameter (mm) | Length (mm) | Cross Section | Shape | Material | Tensile Strength (MPa or N/mm²) |
MFH016006 | 0.16 ± 10% | 6 ± 1.5 | round | Straight | carbon steel 1.4301 / AISI 304 1.4401 / AISI 316 to be negotiated | min. 1400 |
MFH016010 | 0.16 ± 10% | 10 ± 1.5 | ||||
MFH016013 | 0.16 ± 10% | 13 ± 1.5 | ||||
MFH016014 | 0.16 ± 10% | 14 ± 1.5 | ||||
MFH175006 | 0.175 ± 10% | 6 ± 1.5 | ||||
MFH175010* | 0.175 ± 10% | 10 ± 1.5 | ||||
MFH175125* | 0.175 ± 10% | 12.5 ± 1.5 | ||||
MFH175014* | 0.175 ± 10% | 14 ± 1.5 | ||||
MFH020006* | 0.20 ± 10% | 6 ± 1.5 | ||||
MFH020010* | 0.20 ± 10% | 10 ± 1.5 | ||||
MFH020013* | 0.20 ± 10% | 13 ± 1.5 | ||||
MFH020014* | 0.20 ± 10% | 14 ± 1.5 | ||||
MFH030125 | 0.30 ± 10% | 12.5 ± 1.5 | ||||
MFH030020 | 0.30 ± 10% | 20 ± 1.5 | ||||
MFH033125 | 0.33 ± 10% | 12.5 ± 1.5 | ||||
MFH033020 | 0.33 ± 10% | 20 ± 2 | ||||
MFH040125* | 0.40 ± 10% | 12.5 ± 1.5 | ||||
MFH040020 | 0.40 ± 10% | 20 ± 2 | ||||
MFH040025 | 0.40 ± 10% | 25 ± 2.5 | ||||
Packing | in bags of 20 / 25/ 500 / 1000 Kgs net each, 500/1000/1200Kg on pallets, as the request | |||||
Remarks | 1. Micro steel fibers comply with ASTM A820 TYPE I standard. Brass Coated Steel Fibers with Marks* comply with CE Certificate EN 14889-1: 2006. 2. If you would have any special requirements of the specifications, I.E. diameter, length, tensile strength, materials etc., please don't hesitate contact us. | |||||
